地质普查勘探、地球物理勘探、道路及高层建筑物基础勘察、水井、*孔等钻进工程
Geology general check exploration， Earth physics exploration，Road and hihg layer buiding ground survey，Well，last opening et cetera drilling engineering
二、技术参数：Specifications
1、整机参数：Unity *chine parameter
钻孔深度（Drilling depth）………………… ……………100m
*大开孔直径*ximum open hole caliber…………………300mm
终孔直径 End hole caliber……………………………………75mm
钻杆直径 Drill rod caliber………………………………………50mm
钻孔倾角 Drilling angle…………………………………………90~75
钻机重量（不含动力）Drill weight（No include power）……520kg
整机外形尺寸Unity *chine dimensions ………………2*0.9*1.4m
2、立轴Spindle
立轴转速Spindle speed……………………142.285.570r/min
立轴行程 Spindle stroke…………………………………………450mm
3、卷扬机Hoist
单绳*大起重量*x.xingle line hoisting capacity…………1600kg
钢丝绳直径 Tightrope caliber………………………………11mm
钢丝绳容量Tightrope cubic measure…………………………27m
抱闸直径Hug floodgate caliber………………………………230mm
闸带宽度Hug floodgate belt width……………………………50mm
4.泥浆泵Mud pump
类型Type …………卧式单缸双作用Horizontal single urn twin-action
流量Displacement………………………………………………95/77L/min
*大压力*ximum pressure……………………………………1.2Mpa
工作压力Work pressure…………………………………………0.7Mpa
进水管直径Water inlit caliber…………………………………42mm
出水管直径Water to exit caliber……………………………….32mm
5.动力Power
柴油机*sel engine…………………………………………………………………18HP
额定转速Speedlimit…………………………………………………2000r/min
电机Electric motor……………………………………………………………………11kw
额定转速…Speedlimit………………………………………………1460r/min
